Description
Technical Specifications
| Specifications | Technical Parameters |
|---|---|
| Testing Principles | Through reflection photometer to evaluate the color change of urinalysis strip, then calculate the concentration of related items and output semi-quantitative results |
| Testing Wave Length | 470nm, 525nm, 625nm |
| Testing Seed | 500 samples / hour |
| Stray light | Relative intensity ≤ 1% |
| Linearity | Linear correlation coefficient ≥0.995 |
| Repeatability | Coefficient of variation CV≤1％ |
| Stability | During 8 hours of operation, Coefficient of variation CV≤1％ |
| Output Options | LCD display, serial port output, Embedded 57mm thermal printer (English/Chinese), External parallel dot matrix printer，(English/Chinese) |
| LCD Screen | 240x64 dot-matrix LCD |
| Report Storage | Stores up to 2000 sets of results |
| External Ports | RS-232C connected with PC 25 pin centronics port which can driver a dot external printer |
| Working Voltage | AC100-240V 50/60Hz |
| Power | ≤ 45 w |
| Dimension | 390X330X210 mm |
| Weight | 6 kg |
Working and Storage Condition
| Parameters | Working Condition |
Storage Condition |
|---|---|---|
| Temperature | 10℃~30℃ | -20℃~50℃ |
| Relative Humidity | ≤80% | ≤93% |
| Atmospheric Pressure | 76-106Kpa | 76-106Kpa |
| Working Condition | Stable Table, avoid direct strong light and strong electromagnetic interference source | Clean, Ventilative, Stable |
